300T Self-propelled Barge

Overall length: 39.5m

Total width: 9.0m

Moulded depth: 2.0m

Load capacity: 300T

Design full load draft depth: 1500mm

Rated deck load: 6T/㎡

Design no-load draft depth: 800mm

Non-load speed: 20km/h

Full-load speed: 15km/h

Item Deck barge Note
Main dimensions and parameters Overall length 39.5m
Total width 9.0m
Moulded depth 2.0m
Load capacity 300T
Design full load draft depth 1500mm
Rated deck load 6T/㎡
Design no-load draft depth 800mm
Non-load speed 20km/h
Full-load speed 15km/h
Floating body materials baseboard 12mm Surface blasting and rust removal, spraying 4 layers of epoxy zinc-rich marine special paint.
Side plate 6mm
Bottom plate 8mm
Length 35m
Width 9.0m
Height 2.0m
Plate material CCSA/B Marine board
Propeller(2 sets) Diameter of impeller 800mm
Engine Manufacturer  Weichai Marine
Model WD615
Power 145kwX2
Rotation speed 900r/min
Control room Length 3.0m The upper and lower layers are designed to effectively save the usable area. Wall color is white, material is steel, door window is  aluminium alloy sliding type
Width 2.6m
Height 1.9m
Crew lounge Length 4.0m
Width 3.0m
Height 2.0m
Passage deck Length 4.5m Can be lifted up and down
Width 4.2m
Anchor 1 set
Total power: 290kw
Generator set: 20kw
Fuel consumption of equipment(full speed): about 22L/h
Total weight: about 130 ton
Production period: 50 working days
